High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling

1SET
MOQ
2989-3383USD
قیمت
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling
امکانات گالری توضیحات محصول درخواست نقل قول
امکانات
مشخصات
سرعت: 1500 دور در دقیقه
فرکانس: 50/60 هرتز
قدرت امتیازی: 5 کیلووات تا 2000 کیلووات
نوع خروجی: AC سه فاز
تایپ کنید: باز یا بی صدا (فوق العاده بی صدا)
رنگ: در نیاز شما، سفارشی
برجسته کردن:

Silent diesel generator 64KW,Water cooling diesel generator 80KVA,Yunnei silent type generator

,

Water cooling diesel generator 80KVA

,

Yunnei silent type generator
اطلاعات اولیه
محل منبع: چین
نام تجاری: QUANCHAI
شماره مدل: YN48ETD77
پرداخت
جزئیات بسته بندی: تخته سه لا
زمان تحویل: 40 روز کاری
شرایط پرداخت: L/C، T/T
قابلیت ارائه: 50 ست در ماه
توضیحات محصول
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA
High quality water cooling QUANCHAI diesel generator available in both open and silent configurations to meet diverse operational requirements. This reliable power supply unit delivers consistent performance for various applications.
Key Features
  • Equipped with famous brushless alternator brands: Leroy Somer, Marathon, BOBIG, Mecc Alte
  • 50°C radiator with fan for optimal engine cooling during extended operation
  • Advanced control systems including generator set control, ATS system, remote control, and parallel operation
  • High-quality steel canopy construction (2MM to 6MM thickness)
  • High-density sound-absorbing material for effective sound insulation and fireproofing
  • 12V/24V DC battery with charger and connecting wires
  • 10-12 hours fuel tank with fuel indicator for continuous operation
  • High protection class control box (IP55) with waterproofing, electric leakage protection, and breaker
  • Turn-back type air inflow & outlet design reduces noise and improves engine efficiency
  • Practical design with bottom holes for forklift, water outlet, and oil outlet for easy maintenance
  • Double open doors on both sides for comprehensive engine and alternator access
  • Available in silent, super silent, soundproof, trailer type, and container type configurations
  • Compliance with major standards: GB/T2820, ISO8528, IEC34, CE, EPA Tier4
Technical Specifications
General Information
General informationPrime powerStandby power
Rated Power (kVA)8088
Power Rating (kW)6470
Frequency (Hz)50
Engine ModelYN48ETD77
Engine Speed (RPM)1500
Phase3
PF0.8
Control SystemDigital
Rated voltage (V)400/230
Fuel tank capacity operating time≥ 8h @ 75% load
PRP (Prime Power): Available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP (Standby Power): Applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Dimensions and Weight
Dimension and WeightOpen typeSilent type
ModelBYN88BYN88S
Length (L) mm20502750
Width (W) mm8001000
Height (H) mm17501350
Tank capacity (L)147147
Engine Specifications
Engine model & manufacturerYN48ETD77(YUNNEI)
Engine modelYN48ETD77
Engine Rated Speed (rpm)1500
Generator set Frequency(Hz)50
Engine Prime Power (PRP)(kW)77
Length (L) mm1130
Width (W) mm730
Height (H) mm960
Engine Dry Weight w/o Cooling System (kg)500
Aspiration TypeTurbocharged
Injection TypeDirect
ConfigurationVertical
No. of Cylinders4
Displacement(liters)4.8
Bore(mm)108
Stroke(mm)132
Compression Ratio16.5
Piston Speed (m/s)7.92/9.51
Rotation Direction (from flywheel)Anti-clockwise
Number of Flywheel Teeth130
Flywheel House SizeSAE3
Alternator Specifications
Alternator BrandBOBIG
Alternator ManufacturerFUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator ModelBW-224G
Alternator Rated Power64kw/80kva
Rated voltage (V)230v/400v
Rated frequency50hz
Connecting Type3 Phase and 4 W
Number of Bearing1
Protection GradeIP23
Altitude≤1000m
Exciter TypeBrushless ,Self-exciting, AVR automatic voltage regulating,100% Copper
Insulation ClassH class
Telephone Influence Factor (TIF)≤50
THF≤2%
Voltage Regulation, Steady State≤±1%
Transient State Voltage≤-15%～+20%
Standard Components
  • Heavy duty diesel engine
  • Starter battery (with lead acid) including rack and cables
  • Anti-vibration mount
  • Flexible fuel connection hoses
  • Replaceable fuel filter, oil filter & air filter
  • Exhaust silencer and bellows
  • Cooling radiator and fan
  • Operation manuals and circuit diagram documents
Product Images
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 0
Front View
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 1
Side View
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 2
Control Panel
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 3
Engine Detail
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 4
Alternator View
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 5
Silent Type Exterior
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 6
Internal Components
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 7
Cooling System
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 8
Fuel System
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 9
Electrical Connections
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 10
Full Assembly
High Quality Open/Silent Type Yunnei Diesel Generator 64KW/80KVA Power Supply Water Cooling 11
Quality Inspection
Specifications and illustrations are subject to revision without notice.
