Baudouin 264kw 330kw Water CoolingWater Cooled Diesel Generator Engine

1
MOQ
Baudouin 264kw 330kw Water CoolingWater Cooled Diesel Generator Engine
امکانات گالری توضیحات محصول درخواست نقل قول
امکانات
مشخصات
رتبه بندی قدرت: 264 کیلو وات
قدرت نامی: 330KVA
سیستم کنترل: دیجیتال
ظرفیت تانک: 607 لیتر
فاز: 3
فرکانس: 50/60 هرتز
تایپ کنید: بی صدا/باز
برجسته کردن:

Baudouin water cooled diesel generator,330kw diesel generator engine,Baudouin 264kw generator with warranty

,

330kw diesel generator engine

,

Baudouin 264kw generator with warranty
اطلاعات اولیه
محل منبع: چین
نام تجاری: BAUDOUIN
شماره مدل: 6M16G350/5
پرداخت
جزئیات بسته بندی: 285cm*105cm*164.5cm
زمان تحویل: 5-8 روز کاری
شرایط پرداخت: L/C، T/T
توضیحات محصول
Baudouin 264kw 330kw Water Cooling Water Cooled Diesel Generator Engine
Product Overview

Baudouin 264KW 330kva Digital Panel Super Silent Diesel Genset - Model 6M16G350/5. A dependable power generator for industrial and commercial environments. We offer various power configurations that can be customized according to your needs.

Please feel free to contact us!

Baudouin 264kw 330kw Water CoolingWater Cooled Diesel Generator Engine 0
Technical Specifications
General Information Prime Power Standby Power
Rated Power (kVA) 330 363
Power Rating (kW) 264 290
Frequency (Hz) 50
Engine Model 6M16G350/5
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated Voltage (V) 400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time ≥ 8h @ 75% load
PRP - Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP - The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Baudouin 264kw 330kw Water CoolingWater Cooled Diesel Generator Engine 1
Dimensions and Weight
Model BBDA363 (Open Type) BBDA363S (Silent Type)
Length (L) mm 2850 4200
Width (W) mm 1050 1600
Height (H) mm 1645 2250
Tank Capacity (L) 607 607
Engine Specifications
Engine Model & Manufacturer 6M16G350/5 (BAUDOUIN)
Engine Model 6M16G350/5
Number of Cylinders / Valves 6/24
Cylinders Arrangement In line
Bore x Stroke (mm) 126 x 130
Displacement (L) 9.726
Thermodynamic Cycle Diesel 4 stroke
Firing Order 1-5-3-6-2-4
Mean Piston Speed (m/s) 6.5
BMEP @ ESP (Bar) 26.32
Cooling System Liquid (water + 50% antifreeze)
Injection System Direct
Fuel System Mechanical Pump
Aspiration Turbocharged and Aftercooled
Compression Ratio 17:1
Flywheel Housing SAE 1
Flywheel 14"
Rotation Viewed from Flywheel Counter Clockwise
Allowed Static Bending Moment of the Flywheel Housing 10800
Number of Teeth on Flywheel Ring Gear 136
Inertia of Flywheel (kg•m²) 1.84
Inertia of Crankshaft (kg•m²) 0.39
Emission Standard N/A
Overall Dimensions with Radiator (Length x Width x Height) (mm) 1982 x 1082 x 1310
Engine Dry Weight without Radiator and without Radiator Pipes (kg) 880
Engine Dry Weight with Radiator and Radiator Pipes (kg) 1021
Engine Wet Weight with Radiator (includes oil, coolant) (kg) 1092
Alternator Specifications
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-314D
Alternator Rated Power 264kw/330kva
Rated Voltage (V) 230v/400v
Rated Frequency 50hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%～+20%
Company Profile

Established in 2004, Fujian Bobig Electric Machinery Co., Ltd. is an electrical machinery manufacturer specializing in technological research, production and sales. With a total factory area of 10,000 square meters, including 1,000sqm standard construction area, we have 160 employees, including 20 technicians.

Our main products include air-cooled gasoline generators, air-cooled diesel generators, air-cooled welding & generating sets and water-cooled diesel generator sets. Our small air-cooled brushless generators and welding & generating sets have earned a great reputation in the market for their reliable quality.

We adhere to the principle of "Quality, Creation, Service and Development", continuously updating technology, improving quality and providing better service. Our advanced testing equipment includes CAD system, auto assembling & winding & inserting equipment, vacuum dipping system and digital testing equipment.

We maintain strict quality control and have obtained ISO9000 Quality System Certification. We welcome you to build sincere cooperation with us.

Baudouin 264kw 330kw Water CoolingWater Cooled Diesel Generator Engine 2 Baudouin 264kw 330kw Water CoolingWater Cooled Diesel Generator Engine 3
After Sales Services

As a leading Chinese diesel generator manufacturer, we offer comprehensive export services to meet global market needs:

  • Customized manufacturing
  • Quality control
  • International logistics
  • Documentation and certification
  • Trade support
  • After-sales service
  • Customer training
  • Market support
  • Technical collaboration

We deliver tailored diesel generator solutions that meet international quality standards. Our experienced team handles all logistics to ensure timely delivery. We provide necessary documentation compliant with international trade requirements and offer after-sales support including technical assistance and spare parts supply.

Frequently Asked Questions
Q: Are you a manufacturer or a trading company?

A: We are a professional manufacturer with our own factory located in Fujian, China. We welcome you to visit our facility and production line to see our quality control processes firsthand.

Q: What is the minimum order quantity (MOQ)?

A: Our standard MOQ is 1 set. We are flexible and can discuss volume orders for larger projects to provide better pricing.

Q: What is the delivery time after order confirmation?

A: Production time varies by quantity and inventory status. Typically 20-30 days for standard models. We'll provide a precise timeline upon order confirmation.

Q: What payment terms do you offer?

A: We commonly accept T/T with 50% deposit and 50% balance before shipment. For established relationships, we can discuss other terms like L/C.

Q: Do you perform factory inspection before shipment?

A: Absolutely. Every unit undergoes thorough testing in our factory before shipment.
